Description
HMT 5 Axis Dual Stack CNC Tube Bender
Model: CNC18TDRE
Year: 2012
Specifications:
Pipe OD – Maximum…………0.7″ x 0.063″ (18 x 1.6 mm)
Pipe OD for Repeat Feeding – Maximum…………0.79″ (20 mm)
Round Tube – Non-Ferrous…………0.79″ x 0.079″ (20 x 2 mm)
Round Tube – Stainless…………0.7″ x 0.032″ (18 x 0.8 mm)
Square Tube – Mild Steel…………0.59″ x 0.047″ (15 x 1.2 mm)
Round Bar – Mild Steel…………0.315″ (8 mm)
Feeding Speed…………79 IPS (2000 mm/sec.)
Rotation Speed of the Horn tube bender…………320 Deg./sec.
Accuracy Repeatability…………+/-0.01 Deg.
Bending Radius – Maximum…………0.39″ – 3.15″ (10 – 80 mm)
Bending Angle – Maximum…………190 Deg.
Difference between Two Radii – Maximum…………1.18″ (30 mm)
Length over Mandrel – Maximum…………47″ (1200 mm)
Working Height…………43″ (1100 mm)
Tooling Center Line Height…………0.87″ (22 mm)
DOB Speed…………226 Deg./sec.
Machine Dimensions – Actual…………112″(L-R) x 32″(F-B) x 59″(H)
Control Dimensions – Actual…………21″(L-R) x 24″(F-B) x 60″(H)
Weight – Catalog…………1,980 Lbs.
Equipped With:
Programmable Touch Screen Control on Pedestal w/E-stop
Dual Stack Tooling Mount
2-Axis Tool Shift (Head Shift)
Servo Driven Bend-arm (C-Axis), Carriage (Y-Axis), & Collet (B-Axis)
Hydraulic Clamp Die, Pressure Die, & Collet Grip
Automatic Mandrel Lubrication
Anticipated Mandrel Retraction Unit
Ethernet & USB Ports
